HPV4255

HPV4255 MANURE SPREADER INFORMATION

Vertical beaters.

Vertical beaters feature “REVERSE FLIGHTING” on the top 21″ of the beater flighting. This patented feature allows for an even spread pattern of material.

All Hydraulic Push models use solid virgin grade poly with UV inhibitor, for the floor and sides allowing less friction.

The hydraulic endgate has 2 cylinders with ⅜″ hose and pipe for faster operation in cold weather.

Heavy duty rectangular tubing is used for the pole to ensure strength and long life. Structural channel floor supports spaced 9 ½″ apart are used for maximum floor support.

The bottom drive Monoblock Gearbox features an overrunning clutch that provides protection to the driveline.

The Hydraulic Push-Off System on all models features two hydraulic cylinders that sequence to reduce push-off forces for fast unloading of material.

Beater blades are replaceable and the beater assembly is removable for stockpiling manure.

Removal of the beater assembly is done by simply removing the mounting bolts and disconnecting the PTO gearbox driveshaft .
